The latest camera "Raspberry Pi High Quality Camera" from Raspberry Pi offers higher resolution (12 megapixels, compared to 8 megapixels), and higher sensitivity (approximately 50% greater area per pixel for improved low-light performance) than the existing Camera Module v2.
It hosts a Sony IMX477R stacked, back-illuminated sensor which is 7.9mm in diagonal and has a 1.55 μm × 1.55 μm of pixel size. The Package also contains an FPC cable for connection to a Raspberry Pi board, a milled aluminium lens mount with integrated 1/4”-20 tripod mount and focus adjustment ring, and a C- to CS-mount adapter with a dust cap. The box also contains one small screw driver to make minor adjustments.
The High Quality Camera provides an alternative to the Camera Module v2 for industrial and consumer applications, including security cameras, which require the highest levels of visual fidelity and/or integration with specialist optics.
The High Quality Camera supports two primary lenses 6mm Wide and 16mm Telephoto and requires a lens to work. These lenses need to be purchased separately.
6mm Wide and 16mm Telephoto lens
The 6mm wide lens with a 3MP (Mega Pixel) resolution gives a wide field of view covering more objects in its FoV, this features makes it a perfect to cover wide areas with a single camera and lens. This makes its a perfect lens for a CCTV application.
The 16mm Telephoto lens supports upto 10 MP (Mega Pixel) resolution. Being a telephoto lens it provides a high level of zoom over its subject. This feature makes it possible to capture the subject from a distance.
These two lenses directly screw on to the Raspberry Pi High Quality Camera using the C-CS mount adapter which comes with High Quality Camera module. The focus and aperture can be set using the thumb screw on the lens.
The front and the rear lens covers are included in the box.
Raspberry Pi High Quality Camera Specification
Sony IMX477R stacked, back-illuminated sensor
7.9 mm sensor diagonal
1.55 μm × 1.55 μm pixel size
Adjustable (12.5 mm–22.4 mm)
CS-mount and C-mount (C-CS adapter included)
IR cut filter:
Ribbon cable length
FCC 47 CFR Part 15, Subpart B, Class B Digital Device
Electromagnetic Compatibility Directive (EMC) 2014/30/EU
Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU
HQ Camera Lens Specification
|Feature||6mm 3MP||16mm 10MP|
|Resolution||3 Megapixel||10 Megapixel|
|Aperture||F1.2||F1.4 to F16|
|Field Angle||63°||1" 44.6°× 33.6°
2/3" 30.0°× 23.2°
1/1.8” 24.7°× 18.6°
1/2" 21.8°× 16.4°
|Back focal length||7.53mm||17.53mm|
